This time I made a Basic earthquake alarm with the KY-002 Shock sensor. Its can be used for multiple purposes, Like most sensors. In this case we use it as a earthquake sensor.
Step 1: What You Need?
1 x Arduino UNO1 x USB Type-B Cable
1 x RGB LED or 3 Color LED Module KY-016
1 x Shock Sensor KY-002 or Arduino Adjustable Vibration Motion Sensor Module 3-pin
1 x Buzzer or Buzzer Module KY-012
Female-to-Male Jumper Wires
1 x Computer with Arduino IDE installed
All Sensor Module ( include KY-016, KY-002, KY-012) can be found in 37 Types Sensor in 1 Starter Learning Sensor Kit
Optional
1 x Mini Breadboard
Male-to-Male Jumper Wires
USB To Power Jack Cable
Don't have components? Don't worry. Just click the component's name.
Step 2: Build Your Circuit.
Connect wire like the schematic above.
Step 3: Upload The Code.
